PCT高压老化试验机

产品特点Product Features

1. 采用进口微电脑控制饱和蒸气温度、微电脑 P.I.D 自动演算控制饱和蒸气温度。

2. 采用指针显示正负压表；时间控制器采 LED 显示器；自动水位控制器,水位不足时提供警示。

3. 圆型内箱,不锈钢圆型试验内箱结构,符合工业安全容器标准, 可防止试验中结露滴水设计.。

4. 圆幅内衬,不锈钢圆幅型内衬设计,可避免蒸气潜热直接冲击试品.。

5. 精密设计,气密性良好,耗水量少,每次加水可连续 200h。

6. 自动门禁,圆型门自动温度与压力检知安全门禁锁定控制,专利安全门把设计,箱内有大于常压时测试门会被反压保护。

7. 内压力愈大时,专利packing,箱门会有反压会使其与箱体更紧密结合,与传统挤压式完全不同,可延长packing寿命。

8. 临界点 LIMIT 方式自动安全保护,异常原因与故障指示灯显示。

9. 安全阀，当锅内压力超过最大工作值自动排气泄压。

10. 一体成型硅胶门垫圈，气密度良好，且使用寿命长。

1. The temperature of saturated steam is controlled by imported microcomputer and microcomputer P.I.D automatic calculation.

2. The pressure gauge displays positive and negative pressure via a pointer; the time controller uses an LED display; the automatic water level controller provides an alarm when the water level is insufficient.

3. The circular inner chamber, constructed with stainless steel, complies with industrial safety container standards and incorporates a condensation prevention design to avoid water droplets during testing.

4. Stainless steel circular liner design prevents direct steam latent heat impact on test specimens.

5. Precision-engineered design ensures excellent airtightness and low water consumption, with a continuous operation time of 200 hours per water refill.

6. Automatic access control with round doors featuring temperature and pressure detection for secure locking. The patented door handle design ensures that doors exceed normal pressure will be protected against backpressure.

7. The higher the internal pressure, the greater the backpressure generated by the patented packing mechanism on the box door, resulting in a tighter seal with the box body. This design differs significantly from traditional compression-type systems and extends the packing's service life.

8. Automatic safety protection via the LIMIT method at critical points, with abnormal causes and fault indicator lights displayed.

9. Safety valve automatically releases pressure when the pressure inside the pot exceeds the maximum working value.

10. A one-piece molded silicone door gasket with excellent air tightness and long service life.
